Show a smaller block above a broader lower level on spacious blue guides. State the shared interface before adding volumes or counting the exposed surface.
Set up a drawing sheet, then export at full size for accurate triangles.
Preparing the live paper preview…
Enable JavaScript for the live editor and file downloads. The original preset specifications, static preview, printing instructions, FAQs, and template links remain available below.
Write the lower and upper dimensions before locating their shared plane. The illustration can show a stepped form while each block retains its own volume term. Keep the contact convention explicit so adjacent parts are not accidentally described as overlapping solids or separated diagram components.
Label which face region belongs to the contact between levels. It is counted inside each block's complete surface calculation but disappears from the combined outside surface. Use the larger reference steps for this annotation rather than letting shading alone decide what is exposed.
Place the two volume terms and interface-area note beside the same figure. A3 gives room for a broad base and handwritten explanations without changing the ten-millimeter edge rhythm. The outline remains a geometry study rather than a structural design or a materials schedule.
Original triangle edges are ten millimeters, with #3B82F6 strokes at 0.35pt and guide dots initially disabled. The starting A3 boundary is 297×420 mm297 \times 420\,\mathrm{mm}297×420mm with linked twelve-millimeter borders, leaving a nominal 273×396 mm273 \times 396\,\mathrm{mm}273×396mm field. Try a shared-face label and level shading against the reference before committing the full exercise.
Standard guide families are vertical and thirty degrees either side of horizontal. Their horizontal column pitch is approximately 8.660mm, with a five-millimeter half-row pitch. An enclosing cuboid can reserve paper space for the stepped form, while its dimensions must not be substituted for the actual two-block volume or outside surface.
Identify two non-overlapping blocks and keep their shared boundary as a zero-thickness interface. Add the stated volume terms without treating the contact plane as another solid. The assigned unit convention should be written before either level is drawn or counted.
Calculate each closed block's surface separately, then remove the two copies of the shared face when counting the combined outside boundary. Label the interface area explicitly. This explains why adding volume terms and adding complete block surfaces require different handling.
Use a level key that distinguishes the smaller upper form and the larger lower form. Add labels around the most crowded contact edges rather than relying on visible line density. Retain the annotated study with its background choice and stated stacking convention.
Assign one lattice step to one object unit. Use a 12×6×212 \times 6 \times 212×6×2 lower block and an 8×4×38 \times 4 \times 38×4×3 upper block resting on it, with no overlap and no diagram gap. Centering the upper footprint leaves two units along either lower length end and one along either depth side. The block volumes are 144 and 96 cubic units, totaling 240. Their shared interface is 8×4=328 \times 4 = 328×4=32 square units, leaving forty square units of the lower top exposed. Complete separate block surfaces are 216 and 136 square units; subtract the interface twice to obtain 216+136−64=288216 + 136 - 64 = 288216+136−64=288 square units of combined outside surface. Original paper edge runs are 120, 60, and 20mm below and 80, 40, and 30mm above. An enclosing 12×6×512 \times 6 \times 512×6×5-step cuboid reserves a conservative projected envelope approximately 155.885×140 mm155.885 \times 140\,\mathrm{mm}155.885×140mm within the A3 field. Add all outlines, level shading, labels, and calculations manually.
This reference describes the named starting configuration. The live preview and downloads follow your current settings.
Write the lower and upper assigned dimensions and place the upper footprint on the lower top plane. State that the parts have no overlap or gap. Calculate their separate volumes and the thirty-two-square-unit interface before deciding which contact edges to show.
Use consistent guide families for both blocks and label the centered footprint offsets. Try a level key or shading convention beneath the blue references. Keep the shared face separate from exposed top regions, and adjust stroke appearance around the crowded interface annotations.
Export current A3 settings and add the labeled stack at full-page size. Measure twelve original edge steps as 120mm along the lower length direction. Save the annotated calculation sheet and background address together after checking the contact-plane and unit labels.
The initial PDF has a 297×420 mm297 \times 420\,\mathrm{mm}297×420mm A3 boundary and vector blue strokes. Keep that full extent when adding the stack and calculations. Match stock and Actual Size for ten-millimeter steps, then inspect the smallest interface label on the completed print.
Original portrait raster output is 3508×49613508 \times 49613508×4961 pixels at nominal 300 DPI. Preserve the complete border-inclusive A3 image during placement. Recheck the long lower edge after any receiving-app fit or scale operation so the annotated copy retains its intended physical reference.
A vector master can keep the lattice below each level's outline, face treatment, and contact annotations. Preserve physical A3 dimensions while refining those layers. The saved composition carries the stacking convention and calculations that the blank export and shared configuration do not contain.
Adobe's PDF page-sizing guidance describes scaling controls. W3C's paper-size definitions document standard page dimensions.
Compare another coordinate background for your drawing or notes.
A3 ten-millimeter blue isometric paper provides a spacious reference for a two-level solid whose parts meet at a named interface. The larger edge rhythm gives the author room to label both blocks and their contact region, while the standard guide families keep corresponding edges parallel. The background itself supplies no stacked geometry, unit convention, or construction requirement. Those decisions remain explicit in the annotated exercise.
The worked stack makes volume and outside-surface addition different operations. Two non-overlapping block interiors contribute separate volume terms, while their contact plane appears twice when complete individual surfaces are added. Removing both copies gives the combined outside boundary, and subtracting the upper footprint from the lower top gives another separately named exposed region. The conservative enclosing cuboid reserves paper space without being mistaken for the actual occupied form.
A retained master includes the centered placement, no-overlap convention, level key, and square-versus-cubic unit labels beside its reproducible blue reference. Test the crowded contact annotation against the line treatment and deliberately preserve the full A3 extent when original ten-millimeter steps matter. Measure the lower edge after composition and inspect the final copy. Saving that checked exercise with the selected background address preserves both repeatable alignment and the explanation needed to understand the stack's 240-cubic-unit and 288-square-unit results.
