A3 5mm Blue Polar Paper — 12 Spokes

Sample a radial profile that stays above zero while its radius changes with direction. Use the broad blue A3 field for points, a formula, and their stated units.

Free to use
Print ready
PDF, PNG, SVG
Custom sizes

Polar Grid Preview

Choose your radial and angular divisions, then export an accurate plotting sheet.

Preparing the live paper preview…

What Can You Create?

A varying radius with a positive offset

Write a baseline radius and a sinusoidal contribution before locating any samples. The baseline can keep the evaluated radius positive through the full turn. Label that formula and its units so a reader sees a deliberately chosen geometry study rather than an unexplained circle-like outline.

Cardinal samples beside intermediate directions

Begin with right, up, left, and down, then add thirty-degree directions to inspect how the profile changes. Equal angular steps can produce unequal radial differences. Keep both the calculated value and its plotted position visible rather than interpreting the regular spoke rhythm as uniform radial growth.

A large annotated curve discussion

Reserve space around the plot for the sample table, unit convention, and interpolation notes. A3 increases the reference field while retaining five-millimeter rings. The generator creates the blank polar layer; the chosen function, sample marks, and connecting curve remain authored additions.

Why Users Love This Tool

Thirty-degree references with a familiar radial gap

Original twelve-spoke directions are thirty degrees apart, with seven-point degree labels at every spoke and the origin marker on. The #3B82F6 references use 0.35pt strokes and five-millimeter ring spacing. Test the sample labels against that treatment before adding a curve or changing angular text density.

A broad A3 allowance for a sixty-millimeter profile

The initial 297×420 mm297 \times 420\,\mathrm{mm} page uses linked twelve-millimeter borders and center (148.5,210) mm\left(148.5, 210\right)\,\mathrm{mm}. Twenty-five circles reach a 125mm outer radius under the starting label layout. The example's radii range from twenty to sixty millimeters, leaving substantial original radial room for a deliberately placed explanation and point labels.

Perfect For

Learners comparing radial and angular change

Calculate consecutive sample radii and compare their differences while the angle step stays fixed. Identify the minimum and maximum separately from the selected sample count. The plot's source is the written formula rather than a physical observation implied by the shape.

Teachers explaining an offset function

Separate the constant forty-millimeter contribution from the sine term that ranges between minus twenty and plus twenty millimeters. Ask why the total remains positive. Keep the angular convention and paper units visible so the sampled calculation can be checked independently from its sketch.

Authors retaining a manual profile study

Distinguish computed sample points from the chosen connecting stroke, and write any interpolation convention beside the diagram. Preserve the original annotations when revising guide appearance. A shared blank-grid configuration helps reconstruct the reference but does not store the formula or curve.

Worked profile: r=40+20 sin⁡ ⁣(θ)r = 40 + 20\,\sin\!\left(\theta\right) millimeters

Take θ in degrees\theta\,\mathrm{in}\,\mathrm{degrees} for the stated samples. At 0∘0^{\circ}, 90∘90^{\circ}, 180∘180^{\circ}, and 270∘270^{\circ}, radii are 40, 60, 40, and 20mm, reaching eight, twelve, eight, and four original rings. At 30∘30^{\circ} the radius is 50mm; at 60∘60^{\circ} it is 40+10 3≈57.3205 mm40 + 10\,\sqrt{3} \approx 57.3205\,\mathrm{mm}, between the eleventh and twelfth rings. The equal thirty-degree changes from zero to sixty degrees produce radial increases of ten and approximately 7.3205mm, not equal increments. Because sin⁡ ⁣(θ)\sin\!\left(\theta\right) stays between −1-1 and 1, all radii remain between twenty and sixty millimeters. Original A3 cardinal page positions are (188.5,210)\left(188.5, 210\right), (148.5,150)\left(148.5, 150\right), (108.5,210)\left(108.5, 210\right), and (148.5,230) mm\left(148.5, 230\right)\,\mathrm{mm}. Add the samples, formula, table, and connecting stroke yourself. A varying radius does not describe one circle centered at the origin, even though the background is made of circles.

Original preset specifications

This reference describes the named starting configuration. The live preview and downloads follow your current settings.

Original paper
A3 portrait · 297×420 mm297 \times 420\,\mathrm{mm}
Page insets
Top 12, right 12, bottom 12, left 12 mm
Inset rectangle
273×396 mm273 \times 396\,\mathrm{mm}
Radial field
25 rings · 5mm gaps · 125mm outer radius
Angular interval
12 spokes · 30∘30^{\circ} per sector
Original labels
degrees · 7pt · on; origin on
Polar stroke
#3B82F6 · 0.35pt
Original export sizes
PDF/SVG 297×420 mm297 \times 420\,\mathrm{mm}; PNG 3508×4961 px3508 \times 4961\,\mathrm{px} at nominal 300 DPI
How It Works

How it works in three quick steps.

1

Write the offset and angular convention

State the formula's forty-millimeter baseline, twenty-millimeter sine contribution, and degree inputs. Calculate the twenty-to-sixty-millimeter range before marking points. Keep the source labeled as a mathematical profile rather than presenting the shape as measured directional data.

2

Place cardinal and intermediate samples

Count the required rings at the cardinal angles, then locate the thirty- and sixty-degree examples. Interpolate the approximately 57.3205mm radius between rings. Try sample labels and a connecting stroke against the blue references, keeping their authored roles distinguishable.

3

Proof the full A3 profile master

Export current settings and compose the profile at the complete page extent. Measure the twelve-ring maximum radius as sixty millimeters on the final print. Save the formula, sample method, annotated curve, and selected background address together after inspecting the labels.

Download & Print

PDF for the offset-profile explanation

The original PDF uses a 297×420 mm297 \times 420\,\mathrm{mm} A3 boundary with vector blue references and angular labels. Keep that full extent while adding the sample table. Match stock and Actual Size for five-millimeter rings, then inspect the smallest between-ring annotation on the final copy.

PNG beneath a sampled-profile document

Original portrait output contains 3508×49613508 \times 4961 pixels at nominal 300 DPI. Preserve its full border-inclusive A3 proportions during placement. If a receiving document shrinks the image, recheck the composed maximum radius and retain the written sample values independently from the altered display size.

SVG for separately authored curve layers

Keep blue circles and spokes below computed points, the connecting stroke, table, and formula in a vector master. Preserve the physical A3 extent while editing those annotations. The completed file supplies the profile and method that the blank export and shared settings cannot contain.

Check the finished paper

  1. Preserve the selected A3 page extent through profile composition and match the physical paper to the output.
  2. Use 100% or Actual Size and measure the origin-to-twelfth-ring maximum radius as sixty millimeters.
  3. Read the four cardinal values and the approximately 57.3205mm between-ring sample beside the stated formula.
  4. Keep computed points, connecting-stroke assumptions, and mathematical-source labels visible on the retained annotated master.

Adobe's PDF page-sizing guidance describes scaling controls. W3C's paper-size definitions document standard page dimensions.

FAQ

Frequently Asked Questions

Why does this profile never require a negative-radius reversal?
The sine contribution ranges from minus twenty to plus twenty millimeters, and the constant offset is forty millimeters. Their sum therefore stays between twenty and sixty, always above zero. Those bounds follow from the written formula rather than the number of rings printed by the background. Keep the offset and sine contribution separately identified so a reader can check the range before using the sampled curve or changing its parameters.
Why are radial changes unequal at equal thirty-degree steps?
The angle sequence is regular, but sine does not increase by the same amount across every equal angle increment. The worked radii are forty millimeters at zero degrees, fifty at thirty, and approximately 57.3205 at sixty. Those changes are ten and approximately 7.3205mm. The printed spokes provide equal angular references; they do not imply equal radial increments or make the selected profile a constant-rate radial progression.
Does the offset curve describe one circle centered at the origin?
A circle centered at the polar origin has a constant radius in every direction. This formula's radius varies between twenty and sixty millimeters, so that particular interpretation is incorrect. The circular references only support plotting the changing distances. Write the chosen function beside the samples, and distinguish its connecting stroke from the background rings rather than letting a smooth or rounded silhouette decide the curve's geometric meaning.
How do the four cardinal samples translate to the A3 page?
The original center is (148.5,210) mm\left(148.5, 210\right)\,\mathrm{mm}. A forty-millimeter rightward radius gives (188.5,210)\left(188.5, 210\right), sixty upward gives (148.5,150)\left(148.5, 150\right), forty leftward gives (108.5,210)\left(108.5, 210\right), and twenty downward gives (148.5,230)\left(148.5, 230\right). Upward mathematical offsets are subtracted from page height. These page locations describe the selected cardinal points, while the radius and angle pairs remain their separate origin-relative descriptions. Preserve both conventions in the annotated worksheet.
Do label or paper edits automatically update my saved curve?
They update the generated blank polar reference and may change its current fitting allowance or center. They do not capture or relocate samples, a connecting curve, a table, or a formula added in another application. Recompose those annotations deliberately when the page layout changes. Save the selected background address beside the completed profile master so the current guide settings and the authored sample method remain associated without implying automatic curve generation.

About This Tool

A3 five-millimeter blue polar paper with twelve spokes offers a broad reference for a manually sampled profile whose radius changes with direction. The thirty-degree spokes establish an angular sequence and the rings establish physical radial intervals, while the written function supplies the values. This separation allows the author to explain a positive offset and its changing contribution without suggesting that the circular background itself defines the curve.

The worked profile begins with four cardinal samples and adds intermediate cases to make unequal radial changes visible. Its twenty-to-sixty-millimeter range follows from the formula's constant and sine terms, not from the original 125mm outer field. A between-ring radius requires deliberate placement, and the translated page positions require the downward page-coordinate convention. Labeling those decisions keeps the computed sample marks distinct from an illustrative connecting stroke and from the background circles.

A retained explanation includes the formula, degree inputs, sampling choices, and annotation roles beside the reproducible blue field. Inspect the current layout after paper or text edits, preserve full A3 placement when radial millimeters matter, and measure the final composed maximum radius. Retain the rounding precision used in the sample table. Save that annotated profile with its selected background address. The combination preserves a repeatable reference and the mathematical context needed to reconstruct the changing-radius study independently from the editor.

Original Preset Reference

Polar Paper A3, 5mm, Blue, 12 Spokes; 5mm circles, Blue Lines polar grid reference for worked profile: r = 40 + 20 sin (θ) millimeters
