Build an L-shaped prism from a counted footprint and a stated extrusion height. Larger blue triangle edges give its outline space for dimension labels.

Free to use
Print ready
PDF, PNG, SVG
Custom sizes

Isometric Grid Preview

Set up a drawing sheet, then export at full size for accurate triangles.

Preparing the live paper preview…

What Can You Create?

A footprint with a deliberately removed corner

Start with a bounded square in assigned object units, then identify which corner region is absent. Keep the inner return edges parallel to the same guide families as the outside edges. Label the removed dimensions so the missing region is a counted choice rather than an apparent shading effect.

An extrusion whose height is independent of its footprint

Use the vertical family for a shared prism height while the two angled families describe the base. The larger original steps provide paper space for annotations. Calculate the footprint first, then apply the written height instead of multiplying the outside rectangle as if the corner were still present.

A perimeter and surface-area comparison

Trace the concave footprint boundary and count its segments before estimating a represented surface area. The inner corner adds boundary segments while removing base area. Write which quantity is requested so the projected face outline is not mistaken for volume or for the object's complete outside surface.

Why Users Love This Tool

Coarser edge steps for an easily labeled form

The initial triangle edge is 10mm, with #3B82F6 lines at 0.35pt and guide dots off. Adjacent vertical columns are approximately 8.660mm apart, while the half-row pitch is 5mm. This doubles the physical edge run relative to a five-millimeter lattice without changing the three standard guide directions.

A small object within a known A4 allowance

The starting 210×297 mm210 \times 297\,\mathrm{mm} page uses linked twelve-millimeter borders, leaving a nominal 186×273 mm186 \times 273\,\mathrm{mm} field. Stroke centers stop slightly inside that field to keep full line widths contained. Try the concave corner and its label against the blue references before adopting the current weight or enabling extra intersection dots.

Perfect For

Beginners outlining a concave solid

Locate the removed corner on the footprint before adding any vertical edges. Keep the return edges and height labels visible as the drawing develops. The blank pattern guides direction, but it does not decide which faces remain visible or supply a completed prism.

Teachers connecting area and extrusion

State the assigned object-unit convention and compare the complete base with the cut-out base. Ask for the footprint calculation before the volume product. A separate perimeter trace can show why losing area does not necessarily reduce the boundary length in the same way.

Designers preparing a spacious shape study

Use the larger edge rhythm when a small L-form needs readable labels and inner-corner notes. Reserve a leader area around the conservative projected envelope. Treat this as an illustrative geometry model rather than a specification for a fabricated object or its material requirements.

Worked prism: a twelve-unit footprint extruded two units

Assign one lattice step to one object unit. Begin with a four-by-four-unit base and remove a two-by-two corner, leaving 16−4=1216 - 4 = 12 square units in an L-shaped footprint. Extrude the remaining footprint two units vertically for 12×2=2412 \times 2 = 24 cubic units. A four-step original edge run is 40mm on paper; the vertical height is 20mm. Its enclosing four-by-four-by-two cuboid has a projected envelope approximately 40 3=69.282 mm40\,\sqrt{3} = 69.282\,\mathrm{mm} wide and 60mm high, comfortably inside the nominal A4 field with labels reserved around it. The footprint perimeter remains sixteen units: removing four outer boundary units introduces four return-edge units. Under the stated unit convention, the closed prism's surface area is 2×12+16×2=562 \times 12 + 16 \times 2 = 56 square units. Add those outlines and labels yourself; the blank blue lattice does not subtract corners or calculate solids.

Original preset specifications

This reference describes the named starting configuration. The live preview and downloads follow your current settings.

Original paper
A4 portrait · 210×297 mm210 \times 297\,\mathrm{mm}
Page insets
Top 12, right 12, bottom 12, left 12 mm
Inset rectangle
186×273 mm186 \times 273\,\mathrm{mm}
Triangle side
10mm; horizontal pitch 8.6603mm
Guide directions
Vertical and ±30∘\pm 30^{\circ} · standard anchor · #3B82F6 0.35pt
Intersection dots
Off in original preset; available in settings
Original export sizes
PDF/SVG 210×297 mm210 \times 297\,\mathrm{mm}; PNG 2480×3508 px2480 \times 3508\,\mathrm{px} at nominal 300 DPI
How It Works

How it works in three quick steps.

1

Identify the absent corner and unit scale

Write the full four-by-four base dimensions, removed two-by-two region, and two-unit height. State the one-step convention before drawing. Calculate the remaining twelve-square-unit footprint so the extrusion follows the actual L-form rather than its enclosing square.

2

Trace the return edges along the guide families

Keep the concave boundary parallel to the same two base directions and use vertical guides for the shared height. Test inner-corner labels against the blue strokes. Optional guide dots emphasize intersections but do not choose corners or replace the written dimension convention.

3

Check the composed prism copy

Export current A4 settings, add the prism and calculations at full-page size, and measure five original edge steps as fifty millimeters. Save the annotated L-form with its unit convention and background address after verifying the return-edge labels.

Download & Print

PDF for the L-prism geometry master

The original PDF preserves a 210×297 mm210 \times 297\,\mathrm{mm} page with vector blue lines. Compose the cut-out footprint and labels at that full extent. Match A4 stock and Actual Size for ten-millimeter edge runs, then inspect the concave corner on the finished print.

PNG beneath a prepared extrusion exercise

Portrait output starts at 2480×35082480 \times 3508 pixels at nominal 300 DPI. Its existing margins belong to the whole image. Preserve proportional A4 placement and check the composed edge span after the receiving document has applied any fitting or image-size choices.

SVG for return-edge and dimension layers

Keep the blue lattice below the object outline, removed-region note, and dimension annotations in a vector document. Maintain physical A4 dimensions while editing those layers. Save the completed drawing separately because the selected background link does not contain an L-shaped object.

Check the finished paper

  1. Retain the full A4 page size during prism composition and print on stock matching the selected output.
  2. Use 100% or Actual Size and measure five original triangle-edge steps along a guide family as fifty millimeters.
  3. Read the two-by-two cut-out dimensions and the two-unit extrusion label on the completed master.
  4. Keep footprint, perimeter, surface-area, and volume units separately named beside their calculations before copying the exercise.

Adobe's PDF page-sizing guidance describes scaling controls. W3C's paper-size definitions document standard page dimensions.

FAQ

Frequently Asked Questions

Why is the L-shaped footprint twelve rather than sixteen square units?
The four-by-four starting square contains sixteen square units, and the specified two-by-two corner contains four. Removing that corner leaves twelve in the remaining footprint. The example uses that remainder when extruding the prism two units high, giving twenty-four cubic units. State the removed region explicitly; the blue background cannot infer a cut-out from a blank patch or decide which parts of a drawn base are absent.
Does the corner cut reduce the footprint perimeter?
For this specific corner removal, four units of outer boundary disappear and four units of inner return boundary are introduced. The perimeter therefore remains sixteen units, even though the footprint area decreases from sixteen to twelve square units. This is a property of the stated rectangular corner cut, not a rule for every shape modification. Label the concave segments and count the complete boundary before using it in another calculation.
What is the difference between twenty-four and fifty-six in the example?
Twenty-four is the volume in cubic assigned units: twelve units of footprint area times two units of height. Fifty-six is the surface area in square assigned units for the closed prism: two footprint faces contribute twenty-four, and the sixteen-unit perimeter times two-unit height contributes thirty-two. Those quantities have different units and meanings. Keep them separately named rather than treating a projected paper face as either complete result.
How does a ten-millimeter edge differ from horizontal column pitch?
The original triangle edge is ten millimeters along a guide direction. The standard horizontal component is ten times 3\sqrt{3} divided by two, approximately 8.660mm, between neighboring vertical columns. Four edge steps therefore make forty millimeters along an angled edge, while four column pitches span approximately 34.641mm horizontally. Measure the relevant direction and state the represented-unit convention instead of substituting one paper quantity for the other.
Can the generator add the cut-out, return edges, and surface calculation?
It exports the selected blank isometric pattern with its current paper, geometry, line, and optional guide-dot settings. The L-outline, corner removal, height marks, and calculations are authored outside the tool. Retain the finished annotated master with its unit convention and background address. Rebuilding the blue reference layer alone does not recreate the prism or establish which return edges and faces the illustrator intended to show.

About This Tool

A4 ten-millimeter blue isometric paper offers a coarser triangular reference for a small solid with a concave footprint. The larger edge steps create room for the inner-corner labels that explain an L-shaped form. The three guide directions support corresponding parallel edges while leaving the removed region, height, face visibility, and assigned object units as explicit decisions in the annotated drawing.

The worked prism begins with a full square and identifies its missing corner before calculating the extrusion. That sequence keeps the remaining footprint distinct from the enclosing region. Tracing the complete boundary then provides another useful quantity: a perimeter that remains unchanged for this particular corner cut, despite the lost area. The surface and volume calculations use those different inputs and retain different units, so neither should be read directly from a projected paper face.

A retained geometry master needs its labels and conventions alongside the reproducible blue reference. Test a concave corner and dimension leader against the selected stroke treatment, and inspect the final copy after composition. Preserve the original A4 extent when ten-millimeter edge runs matter, measuring along the relevant guide direction. Saving the annotated L-form with the selected background address preserves a repeatable lattice and the explanation needed to distinguish footprint area, boundary length, closed surface area, and volume.
